NEC iPASOLINK EX Advanced - Modify RSTP Port; RSTP Port

8-88 Set ETH Function
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
8.7.2 RSTP Port
8.7.2.1 Modify RSTP Port
Procedure 8-27
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select RSTP/MSTP Setting. The RSTP/MSTP Setting
window appears.
3. Check if the indicating mode is RSTP, then click Modify STP Port tool button.
 If the indicated STP Mode is not RSTP, change the mode using procedure in
8.7.1 Select STP Mode for Setting Procedure.
Figure 8-125 RSTP / MSTP Setting Window (for RSTP Mode)
The STP Port Setting option window (for RSTP mode) appears.
Indicates RSTP
Modify STP Port tool button
