5.3 Alarm Lights
If an alarm is detected, its SYSTEM LED on the equipment bottom indicates the
condition as well. A faulty part can be located by viewing the current alarm status on
the
WebLCT.
SYSTEM LED lights up if an alarm is generated, and goes off when the condition is
cleared. Following show the locations of LEDs:
5.3.1 iPASOLINK EX/A Controls and Indicators
5.3.1.1 iPASOLINK EX/A
Figure 5-11 iPASOLINK EX/E Bottom View
SYSTEM LED
