Assign PMON/RMON Settings 11-19
iPASOLINK EX Adanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
11.4.1.3 Delete VLAN Counter
Procedure 11-7
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu PMON/
RMON Setting
to select VLAN Counter Setting. The VLAN Counter Setting
window appears.
3. In the VLAN Counter Select tabbed page, click the Delete Counter tool button:
Figure 11-25 VLAN Counter Setting Window
4. The Delete VLAN Counter option window appears. Select a VLAN Counter No.
to be removed, then click the OK button:
Figure 11-26 Delete VLAN Counter Option Window
Confirmation
dialog box appears.
5.
Click the OK button of the dialog box.
Delete Counter tool button
To Next Page
