8.4.4 VLAN Setting (802.1Q Mode)
Procedure 8-8
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select VLAN Setting. The VLAN Setting window appears.
3. In the VLAN Setting tabbed page, click a port number (listed under the Port) to
register VLAN settings.
Figure 8-32 VLAN Setting Window — VLAN Setting Tab
VLAN Setting
option window appears.
VLAN Setting tab
Port Numbers
To Next Page
