NEC iPASOLINK EX Advanced - For VLAN Mode 802.1 Ad

5-12 NETWORK MANAGEMENT
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
5.2.3.2 For VLAN Mode 802.1ad
Procedure 5-4
1.
Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Network Management Setting to select
Port/VLAN Setting. The Port/VLAN Setting window appears.
3. Click Inband Management VLAN Setting link.
Figure 5-15 Port/VLAN Setting Window
Inband Management Setting
option window appears.
Inband Management VLAN Setting
