8-144 Set ETH Function
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
8.10.2.2 Modify Policer Index
Parameters of CoS, Policer Profile No., VLAN ID and Policer Profile Detail
Setting
(EIR, CIR, EBS, CBS) can be modified.
Procedure 8-43
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select QoS/Classification Setting.
3. The QoS/Classification Setting window appears. In the Policer Setting tabbed
page, click the link of target
Policer Index number.
Figure 8-196 QoS/Classification Setting Window
The Policer Setting option window appears.
To Next Page
