9-6 Set Equipment Clock and Synchronization
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
9.2 PTP Mode Setting
9.2.1 Modify PTP Mode
Procedure 9-2
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu
Equipment Clock/Synchronization Setting to select PTP Mode Setting. The
PTP Mode Setting window appears.
3. Click the Modify PTP Mode tool button:
Figure 9-6 PTP Mode Setting Window
Step 1 PTP Mode Setting
option window appears.
Modify PTP Mode tool button
To Next Page
