NEC iPASOLINK EX Advanced - Procedure

CONNECT CABLES 5-23
iPASOLINK EX Advanced: INSTALLATION GGS-000546-01E
5.8.2.3 Procedure
1. Strip the cable jacket.
2. Remove the insulation to expose each conductor:
NOTE: Ensure not to damage the braided wire.
3.
Set contact to each conductor.
4. Seal the crimp.
Tools
•knife
• cutter
• measuring tool, etc.
5.75 ±0.25 mm
