Set ETH Function 8-119
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
8.9.2 Modify LAG Registration
Parameters that can be modified are LAG Name and Distribution Rule only.
Procedure 8-35
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then expand ETH Function
Setting
to select Link Aggregation Setting. The Link Aggregation Setting
window appears.
3. Click the Modify Link Aggregation tool button.
Figure 8-165 Link Aggregation Setting Window
Link Aggregation Setting
option window appears.
Modify Link Aggregation button
To Next Page
