NEC iPASOLINK EX Advanced - Modify Static Entry

8-52 Set ETH Function
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
8.5.3.2 Modify Static Entry
Procedure 8-14
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select FDB Setting. The FDB Setting window appears.
3. Select the Static Entry tab, then click the Entry No. of the target to modify.
Figure 8-65 FDB Setting Window — Static Entry Tab
Static Entry (Static Entry No. xxx)
option window for the selected object
appears.
Entry No.
