9-14 Set Equipment Clock and Synchronization
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
9.2.3 Delete PTP Logical Interface
Procedure 9-4
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu
Equipment Clock/Synchronization Setting to select PTP Mode Setting. The
PTP Mode Setting window appears.
3. Click the Delete PTP Logical Interface tool button.
Figure 9-16 PTP Mode Setting Window
Delete Interface
option window of the selected number appears.
Delete PTP Logical Interface
tool button
To Next Page
