Set ETH Function 8-49
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
8.5.3 Static Entry Setting
8.5.3.1 Add Static Entry
Procedure 8-13
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select FDB Setting. The FDB Setting window appears.
3. In the Static Entry tabbed page, click the Add tool button.
Figure 8-61 FDD Setting Window — Static Entry Tab
Static Entry (Add)
option window appears.
To Next Page
