8-100 Set ETH Function
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
8.7.3.2 Modify Detail MSTP Parameter
Procedure 8-30
1. Launch and log in to WebLCT.
2. In the MENU frame on the left, expand Provisioning, then its submenu ETH
Function Setting
to select RSTP/MSTP Setting. The RSTP/MSTP Setting
window appears.
3. Check if the indicating mode is MSTP, then click Modify Detail STP Parameter
button.
 If the indicated STP Mode is not MSTP, change the mode using procedure in
8.7.1 Select STP Mode for Setting Procedure.
Figure 8-139 RSTP / MSTP Setting Window (for MSTP Mode)
The Detailed STP Parameter Setting option window appears.
Indicates MSTP
Modify Detail STP Parameter
tool button
