NEC iPASOLINK EX Advanced - 5.3 Grounding Cable

CONNECT CABLES 5-3
iPASOLINK EX Advanced: INSTALLATION GGS-000546-01E
5.3 Grounding Cable
Following shows the location of Grounding terminal.
Figure 5-2 Connect Grounding Cable
Detailed descriptions and routing methods are provided in the Section 6. GROUND
iPASOLINK EX/A.
GROUNDING TERMINAL (M5)
example: mounted for V Polarization
example: mounted for V Polarization
