5-22 CONNECT CABLES
GGS-000546-01E iPASOLINK EX Advanced: INSTALLATION
5.8.2.2 Considering to Wear Waterproofing Plug Cover
If the connector of the other end (at the power unit side) is larger than 14.5 mm in
diameter, and is already assembled, put the cable through the Waterproofing Plug
Cover and Watertight Hose through prior to starting the procedure below. See
5
.4 Power Cable also.
Plug Cover Mechanism:
1. Disassemble the Waterproofing Plug Cover.
2. Put the cable into and through the parts.
To Next Page
