8-82 Set ETH Function
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
5. Confirmation dialog box appears. Click the OK button to proceed.
Figure 8-114 Confirmation Dialog Box
6. Information dialog box appears. Click the OK button to proceed.
Figure 8-115 Information Dialog Box
7. The ETH OAM Setting window updates the information. Confirm that the target
OAM MIP Index has been removed.
Figure 8-116 ETH OAM Setting Window — OAM MIP Tab
This step ends the procedure.
