8-58 Set ETH Function
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
4. Assign the appropriate value to each parameter:
Figure 8-75 OAM MEG Setting (Add) Option Window
5. When completed, click the OK button.
Table 8-14 OAM MEG Setting Parameters
Parameter Value Description
MEG Index 1 to 128 Set MEG Index number.
Maintenance Domain Name (text field) Maximum length in total of Maintenance Domain
Name and Short MA Name is 43 characters long.
Short MA Name (text field)
MEG Level 0 to 7 Specify the MEG level.
CCM Enable Enable to output/monitor CCM.
Disable Disable to output/monitor CCM.
ETH-CC Period 3.3 [ms] Set the period of ETH-CC (Continuity Check)
Message.
10 [ms]
100 [ms]
1 [s]
10 [s]
60 [s]
CCM Priority 0 to 7 Specify the priority of the CCM
