NEC iPASOLINK EX Advanced - Page 642

CONTROL ITEMS 4-31
iPASOLINK EX Advanced: OPERATION & MAINTENANCE GGS-000548-01E
4. Set the appropriate values, then click the OK button.
Figure 4-44 MODEM Maintenance Control Option Window
5. Warning dialog box appears.Click the OK button.
Figure 4-45 Warning Dialog Box
6. Information dialog box appears. Click the OK button.
Figure 4-46 Information Dialog Box
The MODEM Maintenance Control window updates the information.
Table 4-3 ATPC Manual Control
Parameter Value Description
ATPC Manual Control On Enable/Disable ATPC Manual Control.
Off
ATPC Manual Power –1.0 to 10.0 Set the transmit power value. [unit: dBm]
