EQUIPMENT SETUP 4-7
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
5. When completed, click the Next button. Radio Configuration >> Step2 Setting
Confirmation Screen
window appears.
6. Confirm that the fields of setup parameters change to blue, then click the
OK button.
Reference Modulation QPSK Select a reference modulation from the list. Available
Reference Modulation differs according to the channel
spacing to use.
This option is enabled depending on the obtained
Software License.
NOTE: Refer to 2.2.1 Radio Functions in
Specification manual for the information regarding
the combinations of Channel Spacing and Reference
Modulations.
8PSK
16 QAM
32 QAM
64 QAM
128 QAM
256 QAM
Radio Mode High Capacity High System Gain can be selected when Channel
Spacing is set to 750MHz.
High System Gain
ETH Bandwidth [Mbps] (read only) Indicates the Ethernet bandwidth value that is
automatically calculated.
TX RF Frequency [MHz] 71125.00 to 73625.00 Values for Sub-Band A, Lower Band.
73375.00 to 75875.00 Values for Sub-Band B, Lower Band.
81125.00 to 83625.00 Values for Sub-Band A, Higher Band.
83375.00 to 85875.00 Values for Sub-Band B, Higher Band.
RX RF Frequency [MHz] (read only) Indicates the incoming radio frequency value.
Frame ID 1 to 32 Set the Frame ID.
TX Power Control MTPC Manual Transmitter Power Control [manual control]
ATPC Automatic Transmitter Power Control [automatic control]
Table 4-2 Detailed MODEM Setting Parameters (2 of 2)
Parameter Value Description
To Next Page
