5-44 NETWORK MANAGEMENT
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
Figure 5-66 Forwarding Filter Entry (Modify) Option Window
Table 5-13 Forwarding Filter Entry (Modify) Parameters (1 of 2)
Parameter Value Description
Entry No. (read only) Indicates the selected Entry No.
Input Index Any Selects the ingress port.
Bridge01 to Bridge06
Output Index Any Selects the egress port.
Bridge01 to Bridge06
Source IP Address x.x.x.x Specify the Source IP Address to output packets.
Source Subnet Mask x.x.x.x Specify the Subnet Mask of the Source IP Address
for output packets.
Destination IP Address x.x.x.x Specify the Destination IP Address to output
packets.
Destination Subnet Mask x.x.x.x Specify the Subnet Mask of the Destination IP
Address for the output packets.
To Next Page
