5-50 NETWORK MANAGEMENT
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
5. When completed, click the OK button. Information dialog box appears.
6. Click the OK button to proceed.
Figure 5-76 Information Dialog Box
7. The IP Access Control Setting window updates the information. Confirm the
display for the modified filter information.
Figure 5-77 IP Access Control Setting Window
This step ends the procedure.
Table 5-14 Forwarding Filter Rule Parameters
Parameter Value Description
Forwarding Filter
Rule
Enable Enables the configured forwarding filters.
Disable Disables the configured forwarding filters.
Default Action Permit Forwards an IP packet that does not meet the
configured conditions.
Deny Discards an IP packet that does not meet the
configured conditions.
To Next Page
