NETWORK MANAGEMENT 5-53
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
5. When completed, click the OK button. Information dialog box appears.
6. Click the OK button to proceed.
Figure 5-81 Information Dialog Box
7. The ARP Setting window updates the information. Confirm the display for the
added ARP information.
Figure 5-82 ARP Setting Window
This step ends the procedure.
Table 5-16 ARP setting Parameters
Parameter Value Description
IP Address x.x.x.x Enter the IP address.
MAC Address x.x.x.x Enter the MAC Address.
