NETWORK MANAGEMENT 5-77
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
3. Tick a box of the target IP Address to release its assignment. Ticking a box on top
selects all the registered addresses.
Figure 5-115 Delete MAC Address Option Window
4. When completed, click the OK button.
5. Confirmation dialog box appears. Click the OK button to proceed.
Figure 5-116 Confirmation Dialog Box
6. Information dialog box appears. Click the OK button to proceed.
Figure 5-117 Information Dialog Box
Tick this box
to select all
To Next Page
