8-12 Set ETH Function
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
4. Assign the appropriate value to each parameter:
Figure 8-10 Other Setting Option Window
5. When completed, click the OK button.
Information dialog box appears.
6.
Click the OK button to proceed.
Figure 8-11 Information Dialog Box
Table 8-3 Other Setting Parameters
Parameter Value Description
Aging On/Off On Enables the FDB (Forwarding Data Base) to delete
the learnt MAC Address if it is not updated for a
certain period specified by the FDB Aging Time.
Off Disables the Aging function.
FDB Aging Time 5 to 163680 Specifies the aging time period when the Aging
function is enabled. [unit: second]
To Next Page
