Set ETH Function 8-105
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
7. Set the appropriate values:
Figure 8-147 Step 1 ERP Setting Window
Table 8-26 Step 1 ERP Setting Parameters (1 of 2)
Parameter Value Description
Ring ID 01 to 16 Assign the ID number of the Ring.
Ring Name (text field) Enter the Ring name to apply. Valid value is 1 to 32 characters long.
Ring Type Major Ring Select a ring type that differs
See Figure 8-148 Definition of Ring Types for reference to select a
valid ring-type.
Sub-Ring
Upper Ring
ID
01 to 16 Specify an ID of Upper Ring to which the Sub-Ring connects. This
option is enabled when the Ring Type is Sub-Ring (Interconnection
Node). Assignment with Ring Port0 must be unique in the Sub-
Ring.
To Next Page
