Set ETH Function 8-149
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
4. Enter the Policer Index number to delete, then click the OK button.
Figure 8-201 Delete Policer Index Option Window
5. Information dialog box appears. Click the OK button to proceed.
Figure 8-202 Information Dialog Box
6. When the process is completed, another Information dialog box appears. Click
the
OK button to proceed.
Figure 8-203 Information Dialog Box
7. The QoS/Classification Setting window updates the information.
Figure 8-204 QoS/Classification Setting Window
This step ends the procedure.
To Next Page
