Set ETH Function 8-167
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
6. Information dialog box appears. Click the OK button to proceed.
Figure 8-230 Information Dialog Box
7. Click the Close button of the Shaper Group Member List option window. The
QoS/Classification Setting window returns.
Figure 8-231 QoS/Classification Setting Window
This step ends the procedure.
Table 8-45 Number of Queue Setting Options
Parameter Value Description
VLAN ID (registered VLAN
#)
Select a Priority Queue Profile number to modify.
Shaper Group 1 to 7 Specifies a selected VLAN to the Shaper Group.
Remaining Selected VLAN is not assigned to any Shaper Groups.
