Set ETH Function 8-195
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
4. Set or disable the Port Isolate, then click the OK button.
Figure 8-271 Port Isolate Option Window
5. Information dialog box appears. Click the OK button to proceed.
Figure 8-272 Information Dialog Box
6. The Port Isolate Setting window updates the information. Verify the displayed
information.
Figure 8-273 Port Isolate Setting Window
This step ends the procedure.
Table 8-49 Port Isolate Parameters
Parameter Value Description
Port Isolate Disable Disables the Port Isolate function.
Isolate GRP# Select the group number to enable Port Isolate.
To Next Page
