Assign PMON/RMON Settings 11-3
iPASOLINK EX Adanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
4. Assign the appropriate settings, the click the OK button.
Figure 11-2 PMON Threshold Setting Option Window
Table 11-1 PMON Threshold Setting (MODEM / SW GRP Tab) Parameters (1 of 2)
Parameter Value Description
RF BBE 15min Occur 0 to 696074000 Specifies the threshold value to detect an RF BBE
condition for a 15-Minute period.
Range of the values depends on the modulation
method.
Recover 0 to 696074000 Specifies the threshold value to clear the RF BBE for a
15-minute period.
Range of the values depends on the modulation
method.
1day Occur 0 to
66823104000
Specifies the threshold value to detect an RF BBE
condition for a 1-Day period.
Range of the values depends on the modulation
method.
Recover 0 to
66823104000
Specifies the threshold value to clear the RF BBE
condition for a 1-Day period.
Range of the values depends on the modulation
method.
RF ES 15min Occur 0 to 900 Specifies the threshold value to detect an RF ES
condition for a 15-Minute period.
Recover 0 to 900 Specifies the threshold value to clear the RF ES for a
15-minute period.
1day Occur 0 to 86400 Specifies the threshold value to detect an RF ES
condition for a 1-Day period.
Recover 0 to 86400 Specifies the threshold value to clear the RF ES
condition for a 1-Day period.
