11-10 Assign PMON/RMON Settings
GGS-000547-01E iPASOLINK EX Adanced: SET NETWORK AND SYSTEM PROVISIONING
5. Information dialog box appears. Click the OK button of the dialog box to
proceed.
Figure 11-11 Information Dialog Box
6. The PMON Threshold Setting window updates the information. Verify the
displayed information.
Figure 11-12 Other Threshold Setting Window
This step ends the procedure.
Table 11-3 Other Threshold Setting Parameters
Parameter Value Description
RX Level TCN Threshold –99 to –30 Specifies the threshold value to generate TCN
RX Level alarm. [unit: dBm]
