11-12 Assign PMON/RMON Settings
GGS-000547-01E iPASOLINK EX Adanced: SET NETWORK AND SYSTEM PROVISIONING
5. Information dialog box appears. Click the OK button of the dialog box to
proceed.
Figure 11-15 Information Dialog Box
6. The PMON Threshold Setting window updates the information. Verify the
displayed information.
Figure 11-16 Other Threshold Setting Window
This step ends the procedure.
Table 11-4 Other Threshold Setting Parameters
Parameter Value Description
SFP TX Power TCN
Threshold
–40 to 8.1 Specifies the threshold value to generate TCN
SFP TX Power alarm. [unit: dBm]
SFP RX Power TCN
Threshold
–40 to 8.1 Specifies the threshold value to generate TCN
SFP RX Power alarm. [unit: dBm]
To Next Page
