Figure 3-7 Monitoring Point and Range for Receiving Level
Figure 3-8 Monitoring Point and Range for Transmitting Level
Figure 3-9 Monitoring Point and Range for Modulating Level
Facility Monitoring Item Monitoring Point Monitoring Range
Near-End
RF RX Level (MAX)
RX Level (MIN)
11
Facility Monitoring Item Monitoring Point Monitoring Range
Near-End
RF TX Power (MAX)
TX Power (MIN)
22
Facility Monitoring Item Monitoring Point Monitoring Range
Near-End
RF TX Modulation 2 2
RX Modulation 1 1
To Next Page
