4-22 CONTROL ITEMS
GGS-000548-01E iPASOLINK EX Advanced: Operation & Maintenance
5. Click the OK button of the option window.
Figure 4-30 LAG Revert Control Option Window
6. Warning dialog box appears. Click the OK button to proceed.
Figure 4-31 Warning Dialog Box
The reverting command is executed.
7. When completed, Information dialog box appears. Click the
OK button to end
the procedure.
Figure 4-32 Information Dialog Box
This step ends the procedure.
To Next Page
