4-34 CONTROL ITEMS
GGS-000548-01E iPASOLINK EX Advanced: Operation & Maintenance
4. Set the appropriate values, then click the OK button.
Figure 4-49 MODEM Maintenance Control Box
5. Warning dialog box appears. Click OK button.
Figure 4-50 Warning Dialog Box
6. Information dialog box appears. Click the OK button.
Figure 4-51 Information Dialog Box
The MODEM Maintenance Control window updates the information.
Table 4-4 TX MuteControl
Parameter Value Description
TX Mute Control On Executes the forced mute.
Off Releases the forced mute. [default]
Release Time No Limit No limitation to auto recovery. This option is not editable.
