CONTROL ITEMS 4-43
iPASOLINK EX Advanced: OPERATION & MAINTENANCE GGS-000548-01E
4. Set the appropriate values according to your system, then click the Search
button.
Figure 4-64 Carrier Search Option Window
Table 4-7 Carrier Search Parameters to Set
Parameter Value Description
Channel Spacing 62.5 MHz Select the Channel Spacing.
125 MHz
250 MHz
500 MHz
750 MHz
1000 MHz
2000 MHz
TX mute (Opposite Site) Off Disables the Mute Setting at the opposing site.
On (Release Time: 90 [s]) Enables the Mute Setting at the opposing site.
