4-72 CONTROL ITEMS
GGS-000548-01E iPASOLINK EX Advanced: Operation & Maintenance
7. The Program File option window displays the selected directory. Click the OK
button.
Figure 4-111 Source Selection Option Window
8. Warning message dialog box appears Click the OK button.
Figure 4-112 Warning Dialog Box
During the process, download progress bar appears.
9. When the download process is completed, the
Update Complete! message
dialog box appears. Check (leave a tick in) the Program ROM Switching
check box, and then click the
OK button.
Figure 4-113 Update Complete! Dialog Box
Warning message dialog box appears.
To Next Page
