5-8 CORRECTIVE MAINTENANCE
GGS-000548-01E iPASOLINK EX Advanced: OPERATION & MAINTENANCE
Table 5-1 List of Conditions for Equipment
Indication Category Description
Mute Status Status Indicates that the control status of the RF TX Power Output is set
to MUTE.
ATPC Power Mode Status Indicates that a failure of APTC control signal (for 90 seconds), or
a status of MAX Power (for 90 seconds) has been detected.
FDB Full Status FDB Full indication is specified per VLAN.
RX Modulation Status Indicates that the modulation system at the receiving side has
been changed.
Total FDB Full Status Dynamic Entry in L2Switch has reached the maximum number.
TX Modulation Status Indicates that the modulation system of MODEM at the
transmitting side has been changed.
CLK Status Changed Status Indicates that a change has been made to Reference Clock.
PTP Radio Clock Status Status Indicates the PTP Radio Clock Status.
Maintenance Status Indicates that the system is set int the Maintenance mode.
Equipment Start-up Status Status Indicates that the equipment is started up, or rebooted, and
reports the cause.
Trap Suppression Status Status indicates the state of Trap Suppression function.
ETH-Ring Status Status Indicates the state of the ETH-Ring.
ETH-Ring Cause Status Indicates the ETH-Ring State changes.
ETH-Ring Multi RPL Owner
Detect
Status Indicates that the system detects the multiple settings of ETH-
Ring RPL.
ETH-Ring Port0 Status Status Indicates that the state changes of the Port configuring ETH-
Ring.
ETH-Ring Port0 Loop Detect Status Indicates that the system detects loops in ETH-Ring traffic.
ETH-Ring Port0 R-APS
Timeout
Status Indicates that the time out for receiving R-APS message occurs
at the node that configures ETH-Ring and has no locked-out
ports.
ETH-Ring Port1 Status Status Indicates that the state changes of the Port configuring ETH-
Ring.
ETH-Ring Port1 Loop Detect Status Indicates that the system detects loops in ETH-Ring traffic.
ETH-Ring Port1 R-APS
Timeout
Status Indicates that the time out for receiving R-APS message occurs
at the node that configures ETH-Ring and has no locked-out
ports.
PTP Sync. Time Status Indicates the time of synchronizing with Master when using the
PTP function.
PTP Clock Quality Level Status Indicates the level of PTP Clock Quality.
Own Clock ID Status Indicates the PTP Clock of the equipment.
To Next Page
