Table 5-2 List of Conditions for ETH
Indication Category Description Severity
Flow Control Status Indicates Flow Control status of the indicated port. ——
LACP Status Status Indicates the current status of Link Aggregation Control
Protocol.
——
LAG LLF Status Status Indicates a LINKDOWN caused by Link Loss
Forwarding. The Ethernet port that is set to the edge
mode is having a LINKDOWN state.
——
LAG Port Loop Detect Status Received LACP Frame has its own MAC Source
Address for its Source Address.
——
LAG Port Status Status Indicates the current status of LAG member ports; ACT
(Active) or SBY (Standby).
——
LLF Status Indicates the setting of Link Loss Forwarding. ——
LLF Message Timeout Status Loss of a conditional signaling in which the LLF control
signal should be received continuously from the
opposite radio equipment.
——
LLF OAM Received Status Indicates that the LINKDOWN control request caused
by Link Loss Forwarding is issued at Dot3ah and LLF
enabled LAN ports on the opposing site.
MDI/MDI-X Status Indicates MDI status of the indicated Ethernet port. ——
Remote Errored Frame Status Received a message that Errored Frame has been
detected at the opposing site.
——
Remote Errored Frame
Period
Status Received a message that Errored Frame Period has
been detected at the opposing site.
——
Remote Errored Frame
Seconds Summary
Status Received a message that Errored Frame Seconds
Summary has been detected at the opposing site.
——
Remote Errored Frame
Symbol Period
Status Received a message that Errored Symbol Period has
been detected at the opposing site.
——
SFP Port Type Status Indicates an SFP Port type, optic or electric. ——
Speed & Duplex Status Indicates a specified LAN Port Setting on speed rate
and duplex mode.
——
ALS Status ALS has suspended the optical output at the indicated
GbE/10GbE Port.
