1-2 OPERATE WebLCT
GGS-000547-01E iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING
1.2.2 Local Port Interface
The DCN (PoE) Port is provided on the equipment:
Figure 1-1 DCN (PoE)
Connect the LAN Port on PC and
DCN (PoE) Port on iPASOLINK EX/A using a
LAN Cable. Following are the specifications of LAN Port/Cable:
10/100BASE-TX
RJ45
1.3 Hardware Requirements
Component Windows 7® (32 bits, 64 bits) Windows 8.1® (32 bits, 64 bits)
CPU Intel Core i5 2 cores 2.0 GHz or greater Intel Core i52 cores 2.0 GHz or greater
RAM 2 GB or greater 2 GB or greater
HDD 40 GB or greater 40 GB or greater
Display Color LCD (1024 × 768) Color LCD (1024 × 768)
LAN Port 10/100BASE-T(X) 10/100BASE-T(X)
USB Port ——— ———
(to DCN (PoE) port
LAN CABLE
(10/100BASE-TX)
DCN (PoE)
