UNIVERGE SV9100 Issue 1.2

System Hardware Manual 3 - 45

3. Metal brackets from the CHS2UG JOINT BRACKET KITs are required

to secure the top end of the chassis with screws. See figure below.

Figure 3-57 Install Additional CHS2UG STAND KIT (EXT)

Expansion

Plates
