Issue 1.2 UNIVERGE SV9100
6 - 50 Installing SV9100 Optional Equipment
24. Connect the line cord to the adapter.
25. Connect the user system (KTS or PBX) cable.
26. If required, remove the side panel from the original cradle unit.
11.5.2 Using the PSA-L Adapter
1. Placing Calls:
When the PSTN line is activated either manually by the switch
or due to a power failure, use the dial pad buttons (0-9, *, #) to
place an outside call. Use the Vol
or to increase or
decrease audio levels.
Other than receiving calls, no other keyset functions are
available.
Figure 6-46 Install Plastic Panels
CAUTION: Before installing or removing the
PSA-L adapter, remove the line cord, LAN cable,
and then AC adapter from the outlet.
