Issue 1.2 UNIVERGE SV9100
6 - 28 Installing SV9100 Optional Equipment
10.1.1 Removing the Faceplate
1. Use the small notch at the lower right corner of the telephone,
to lift the faceplate up.
Each corner has a plastic locking pin which releases as
the faceplate is lifted up.
10.1.2 Replacing the Faceplate
1. Place the faceplate back on the telephone.
2. At each corner, press the locking pin back into place.
Figure 6-18 Removing the Faceplate
