UNIVERGE SV9100 Issue 1.2
System Hardware Manual 5 - 67
telephone. See Figure 5-59 Separating the Tilt Legs.
3. Push downward (two arrows) and slide downward (refer to
Figure 5-60 Remove Tilt Legs from Multiline Terminal.
4. Lift and remove the Tilt Legs.
4.11.2 Install Tilt Legs
1. Place the telephone on a flat surface (button side down).
2. Lay the adjustable Tilt legs on top of the telephone. See Figure
Figure 5-59 Separating the Tilt Legs
Figure 5-60 Remove Tilt Legs from Multiline Terminal
