Issue 1.2 UNIVERGE SV9100
5 - 38 Installing DT Series Digital and IP Multiline Terminals
3.2 DT800 Series IP Multiline Terminals
3.2.1 ITZ-12D-3 (BK)/(WH) TEL
This IP value multiline terminal has 12 line keys and is available in
both black and white. The terminal features:
 Modular design
 Four-step adjustable base
 Seven-color LED for incoming calls
 224 X 96 full dot gray scale LCD with cursor keys
 Backlit Numbered Keypad for easy viewing
 10 Base-T/100 Base-TX network interface
 12 Line buttons
 Menu/Softkey operation provided on the LCD
 Full-duplex handsfree operation
 IEEE 802.3af compliant
 XML open interface
 Backlit LCD
Figure 5-25 ITZ-12D-3 TEL
