UNIVERGE SV9100 Issue 1.2
System Hardware Manual 4 - 5
2.2.2 Order of Installing Extension Blades
The order in which the station blades (GCD-8DLCA, GCD-16DLCA,
GPZ-8DLCB and GCD-4LCA, GCD-8LCA, GPZ-8LCE) are
physically inserted determines the numbering plan.
For example, when a digital station blade (GCD-16DLCA) is in Slot 1
(ext. 200~215) and three additional digital station blades are installed
in the following order, the numbering plan below in Table 4-1
Extension Blade Installation Order Example on page 4-5 applies.
After the initial powering up of the system, subsequent powering up
or resets do not change the slot identification. System programming
(Program 90-05) must be performed to change the slot identification.
Adding any daughter board to increase the available ports or go to a
higher capacity blade (e.g., GCD-16DLCA) may require that the slot
be deleted in programming and the blade reinstalled. In the following
example, to add a daughter board to slot 2, the blade must be
removed, deleted in Program 90-05-01, then reinstalled with the
daughter board attached, otherwise the additional ports are not
recognized. This however, uses new ports for the combined blade –
the initial ports (ports 17~24 using the example below) are not used.
Table 4-1 Extension Blade Installation Order Example
Order of
Installation
Blade Slot
Number
Blade
Extension
Numbers
1 1 GCD-16DLCA 200~215
2 2 GCD-16DLCA 216~231
3 4 GCD-8DLCA
GPZ-8LCE
232~247
4 3 GCD-8DLCA 248~263
To avoid unexpected extension/trunk numbering if
the VoIP or Voice Mail daughter board registers
with the system first, install these boards after
the
other types of extension and trunk blades have
been installed.
