UNIVERGE SV9100 Issue 1.2
System Hardware Manual 2 - 5
SECTION 3 MAXIMUM SYSTEM CAPACITIES
The CHS2UG is a compact 19” chassis that has six universal slots, one expansion
slot and one MPS7101 (power supply unit). When the GCD-CP10 is installed in the
first CHS2UG, it is referred to as the Controlling Chassis. Additional chassis,
referred to as Expansion Chassis, can be installed to increase the capacity of the
system to meet the customer’s business needs.
As Figure 2-3 19” Controlling and Expansion Chassis and Table 2-2 SV9100
Maximum System Capacities – Trunks/Ports/Channels illustrate, the system can be
expanded to a total of 512 ports by vertically stacking a maximum of three additional
chassis onto the controlling chassis. This provides a maximum of 24 slots and 368
digital terminals. To obtain a the maximum port capacity of 512 ports, two systems
can be linked together via an IP connection.
The maximum slot and channel capacities are listed in Table 2-2 SV9100 Maximum
System Capacities – Trunks/Ports/Channels.
Table 2-2 SV9100 Maximum System Capacities – Trunks/Ports/Channels
Number of:
9.5”
Chassis
19” Chassis
System
Maximum
x 1
(CPU + 2
Slots)
x 1
(6 Slots)
x 2
(12 Slots)
x 3
(18 Slots)
X4
(24 Slots)
Number of Timeslots
48 104 208 312 416 416
DT400/DT300 TDM (-48V)
32 80 176 272 368
Tot a l 89 6
SLT (-28V)
32 80 176 272 368
SLT (-48V)
8 20446892
DT800/DT700 IP
896 896
SIP/WLAN
896
Analog Trunks (COT)
16 40 88 136 184
Tot a l 40 0
BRI
16 40 88 136 184
PRI
60 90 180 180 180
IP Trunk (SIP)
400
DTMF Receivers
32 32 32 32 32 96 *1
VoIP Channels
256
To Next Page
