UNIVERGE SV9100 Issue 1.2
System Hardware Manual 6 - 15
SECTION 5 EXTERNAL PAGING
5.1 External Page
Two external page zone/door box circuits are provided by each PGD(2)-U10
ADP installed. Each Door Box/external page circuit provides a dry relay
contact. The GCD-CP10 also provides a connection for external paging and a
relay. The external page on the GCD-CP10 is speaker number 9 - the relay is
number 0. The external page speakers provided by the PGD(2)-U10 ADPs are
1-8 – the relays on the PGD(2)-U10 ADPs are numbered 1~8.
The PGD(2)-U10 ADP can be used for talkback with External Page, as can a
CO trunk port with the proper external page equipment (ex: Valcom) – set
Program 31-06-03 to “0” for talkback. However, the external page circuit on
the GCD-CP10 cannot be used for talkback.
5.2 Installing an External Page System
1. Connecting to the GCD-CP10:
Connect an RCA line from the CN8 or CN9 connector on the GCD-CP10
to the appropriate location on the extension cross-connect block.
2. Connect the two-conductor station cable from the cross-connect block to
the external relay/external page.
3. Install bridging clips as required.
OR
1. Connecting to the PGD(2)-U10 ADP:
Make sure the jumper in the PGD(2)-U10 ADP for the channel is set
correctly. (Refer to Figure 6-4
PGD(2)-U10 ADP Jumper Settings on
page 6-4).
2. If a line cord was not previously connected to the PGD(2)-U10 ADP,
complete Steps 3-6. Otherwise, skip to Step 7.
3. Install a modular jack for each PGD(2)-U10 ADP. For each module, run
one-pair 24 AWG station cable from the cross-connect block to a
modular jack. Ground the unused pair.
