NEC Univerge SV9100 - Connectors

Issue 1.2 UNIVERGE SV9100
4 - 34 Installing the SV9100 Blades
4.1.4 Connectors
The CNx01 connectors provide connection to four digital station
ports. With the GCD-16DLCA blade, the CN101, CN201, CN301,
and CN401 connectors are available. With the GCD-8DLCA blade
the CN301 and CN401connectors are removed from the blade.
Table 4-15 GCD-8DLCA/GCD-16DLCA/ RJ-61 Cable Connector
Pin-Outs on page 4-35 show the pin-outs for the RJ-61 connector.
Refer to Figure 4-9 GCD-8DLCA/GCD-16DLCA/ Blade on page 4-32
for the location of the connectors on the ESIU blades.
Flash (1s) On The assignment of the unit is refused.
When you exceed the system
capacity.
When the main software
version is not matched.
Flash (1s) Trouble found during self-diagnostics. –
Flash
(100ms)
On
Normal
Operation
A Channel is busy (use
another from CH1 ~ CHx).
–
Off All channels are idle. –
Off
On
Unit Busy
A Channel is busy (use
another from CH1 ~ CHx).
–
Off All channels are idle. –
Flash (100ms
On/Off)
Downloading firmware. –
Table 4-14 GCD-8DLCA/GCD-16DLCA LED Indications (Continued)
LED Indication
Operation Status Remarks
Live LED
(Green)
Busy LED
(Red)
Any cabling to the DLCA blade must be within the
building - no outside cabling is permitted.
