UNIVERGE SV9100 Issue 1.2
System Hardware Manual 1 - 5
SECTION 2 EQUIPMENT LIST
The following tables list all equipment for the SV9100 systems.
Table 1-1 Chassis Equipment List
Equipment Name Equipment Description
CHS2UGG 19” Chassis (6-slot)
CHS2UG B 9.5” Chassis (3-slot)
Table 1-2 Chassis Installation Equipment List
Equipment Name Equipment Description
CHS2UG MOVABLE WALL
MOUNT KIT
Movable Wall Mount Set for CHS2UG B
Chassis
CHS BASE UNIT Floor Mount Set for all chassis (CHS2UG)
CHS2UG BLANK SLOT
COVER KIT
Blank Slot Cover Set
CHS2UG JOINT BRACKET
KIT
Upper Joint Bracket for 6-slot Chassis
CHS2UG RACK MOUNT KIT Rack Mount for CHS2UGG Chassis
CHS2UG WALL MOUNT KIT Wall Mount Set for CHS2UG Chassis
CHS2UG Stand Kit (K) Stand Mount Kit for 2UG Chassis
Table 1-3 Battery Mount Equipment List
Equipment Name Equipment Description
CHS2UG B SMALL BATT
BOX
Short-term battery box for 3-slot chassis
Backup time - 10 minutes
CHSG LARGE BATT BOX Long Term Battery Box for CHS2UG
Chassis.
Cable between batteries - 9.06in/230mm
Fuse Unit to batteries - 18.11in/460mm
Cable from chassis to battery box - 81.1in/
2060mm
CHS2UG BATT MTG KIT Battery Mount for CHS2UG Chassis
CHS2UG SMALL BATT SET Short-term set for 3-slot chassis
