Issue 1.2 UNIVERGE SV9100
5 - 40 Installing DT Series Digital and IP Multiline Terminals
3.2.3 ITZ-12DG-3 (BK)/(WH) TEL
This IP value multiline terminal has 12 line keys and is available in
both black and white. The terminal features:
 Modular design
 Four-step adjustable base
 Seven-color LED for incoming calls
 Monochrome LCD
 Backlit Numbered Keypad for easy viewing
 10 Base-T/100 Base-TX/1000 BASE-T network interface
 12 Line buttons
 XML Open Interface support
 Full-duplex handsfree operation
 IEEE 802.3af compliant
 Menu/Soft key Operation
 USB I/F
 EHS I/F (with R2 F/W)
Figure 5-27 ITZ-12DG-3 TEL
